| Basic |
Passage width (Max) |
450mm |
|
Throughput rate |
35 P/M |
|
Power Supply |
100V ~ 240V AC |
|
Operational Voltage |
24V DC |
|
Max Power consumption |
30W |
|
Frequency |
50Hz ~ 60Hz |
|
Protection Level (IP) |
≥ 44 |
|
Working Temperature |
-25° ~ +70° |
|
Electro-magnetic Drive |
DC |
|
Dimension excluding bars |
480 X 280 X 1050 mm |
|
New weight (Including Bars) |
40kg |
| Features |
| – |
Use IC cards, ID cards, bar code or magnetic cards as automatic identification system |
| – |
Display has been in use for statistics and numbers |
| – |
With voice and strobe light alerts |
| – |
A combination of infrared sensors and police anti-illegal entry into pedestrian access |
| – |
Double anti-clipping function, photocell anti-clipping & mechanical anti-clipping |
| – |
The barrier can be set to delay closing in 1 ~ 60s after a valid card reading |
| – |
Single passage in the set direction |
| – |
Bi-directional single passage |
| – |
Free passage in the direction |
| – |
Always free or locked |
