| Basic |
Camera |
Image Sensor : 1/3″low illumination CMOS |
|
Video Format |
PAL/NTSC |
|
Image Resolution |
Main stream:1280×960, 1280×720; Sub-stream(D1) |
|
Lowest Illumination |
Color 0.2Lux @(F1.6,AGC ON), 0 LUX with IR ON |
|
|
B&W 0.1 Lux @ (F1.2,AGC ON),0 LUX with IR ON |
|
Wide Dynamic |
Digital Wide Dynamic |
|
DNR |
2D/3D Noise Reduction |
|
Electronic Shutter |
1/25 – 1/10,000s |
|
Day and Night Mode |
Support IR-CUT |
| Lens |
Focal Length |
4.7mm ~ 84.64mm ( F1.6～F3.6) |
|
Optical Magnification |
18X |
|
Functions |
IR Distance : 120m |
|
Rotation Range |
Horizontal: 0 °~ 360 °continuous rotation; |
|
Vertical |
-15 °~ 90 ° continuous monitoring after auto flip180° |
|
Preset point |
255 |
|
Automatic Mode |
Preset point/preset point cruise/horizontal |
|
|
scan/auto scan/path/random scan |
|
Network Protocol |
TCP/IP, HTTP, DDNS, DHCP, NTP, |
|
|
PPPoE, FTP, SMTP, RTSP, RTP |
|
Storage Function |
Network storage, support for |
|
|
microSD card storage(optional) |
| Input / Output |
Network Interface |
1x RJ45 10M/100M adaptive Ethernet port |
| Power |
Power |
DC 12V±10% / 4A |
|
power consumption |
≤35W |
| General Specifications |
Work Environment |
Temperature -30~65OC; Humidity <90% RH |
|
Protection Class |
IP66 full dustproof,waterproof |
| Dimension |
Dimension |
Φ185mm x 316.5mm |
|
Weight |
2.6Kg |
| Features |
| – |
HD 960P resolution; image clarity and detail |
| – |
Support IR-CUT, to achieve day and night surveillance |
| – |
Support three-dimensional intelligent positioning |
|
function, enable tracking and enlarge by clicking |
| – |
Advanced video compression technology, ultra-low |
|
bit-rate, high-definition picture quality |
| – |
Support several kinds of phone remote monitoring（iOS, Android) |
| – |
Supports multiple browser access（IE, Chrome, Firefox, Safari) |
| – |
Automatic electronic shutter function, adapt to Scenarios |
|
different environmental monitoring |
|
Support ONVIF standard |
| – |
Supporting web, CMS, center platform management |
