| Specification |
|
| Number of doors controller |
1 Door |
| Numbers of readers supported |
4(2 RS-485 Reader, 26-bit wiegand reader) |
| Types of readers supported |
26-bit Wiegand and RS485 FR Series Reader |
| Number of Inputs |
3( Exit Device, 2 Door Status, 1 AUX) |
| Number of Outputs |
2 (1-Form C Relay for Lock and 2-Form C Relay for Aux Output) |
| Card holders Capacity |
30,000 |
| Fingerprint Capacity |
3,000 |
| Log Events Capacity |
1,00,000 |
| Communication |
TCP/IP and RS-485 |
| Package Dimension |
350(L)×90(H)×300(W)mm |
| Package Weight |
3.6 kg |
| CPU |
32 bit 400MHz CPU |
| RAM |
32MB |
| Flash Memory |
128MB |
| Power |
9.6V-14.4V DC |
| Operating Temperture |
0 – 45 °C |
| Operating Humidity |
20% to 80% |
|
|
Features |
| – |
Embedded Fingerprint verification and advance |
|
access control function |
| – |
It can be installed easily on your network also |
|
support TCP/IP and RS485 communication |
| – |
1/2/4 Door models can be mixed and matched in |
|
an optimised System Architecture |
| – |
Data is preserved if power is lost, Controller |
|
continues to operate if data connection is interrupted |
|
Anti-Passback, First-Card Opening, Multi-Card Opening |
| – |
Duress Password Entry, and Auxilary input/output |
|
linkages are inbuilt into controller firmware |
|
Software and Database Supported : |
| – |
Access Security System 3.5 (Desktop Version) |
|
Database Type:- MS Access / MS SQL |
| – |
|
|
|
|
