| Specification |
|
| Camera Performance |
|
| Image Sensor |
1/4″ SONY CCD |
| Zoom |
18X optical zoom, 12X electrical zoom |
| Minimum Illumination |
0.1 Lux |
| Aperture |
Automatic aperture; electrical zoom preferred |
| Focus |
Automatic focus; electrical zoom preferred |
| Main processor |
Hi3512 |
| Operating System |
Built-in Linux |
| Resolution |
H.264 main profile level 3, 480 TVL resolution |
| Video Resolution |
Main stream: 704 x 576, 352 x 288, 176 x 144 optional |
|
Secondary stream: 352 x 288, 176 x 144 optional |
| Function Interface |
|
| Audio Input |
1 channel line input |
| Audio Output |
1 channel line output |
| Alarm Input |
1 channel on/off input (NO/NC settable) |
| Alarm Output |
1 channel on/off output, external max |
| working voltage |
120V AC 1A/24V DC 1A |
| Storage |
Support local SD card to store video and snap |
|
up to 64G |
| Network Interface |
10Base-T/100Base-TX Ethernet |
|
interface; WIFI 802.11b/g/n wireless network (optional) |
| Protocols |
TCP/IP, HTTP, TCP, UDP, ARP, SMTP, FTP |
|
DHCP, DNS, DDNS, NTP, UPNP, RTSP PTZ |
| Horizontal Speed |
0.1° ~ 250°/S |
|
|
|
| Vertical Speed |
0.1° ~ 100°/S |
| Preset Position |
Vertical: 100°/S |
| Speed |
Horizontal: 250°/S |
| Auto Scanning Speed |
1° ~ 40°/S settable |
| Pan Movement |
360º continuous pan |
| Tilt Movement |
0° ~ 92° tilt |
| Scanning Mode |
Automatic/random/preset position tour |
| Preset Position |
255 preset positions, precision<0.1 |
| Preset Position Speed |
Vertical:100°/S Horizontal:250°/S |
| Limit Card |
Scanning limit and control limit can be set |
| Trace |
Two trace memory functions |
|
|
| Work Environment |
|
| Power Supply |
18V AC~24V AC, 3A |
| Power Consumption |
30w max(no heater) |
|
40w max(heater) |
| Working Temperature |
-40°C ~ 55 °C |
| Protection Rating |
IP66 |
| Optional |
PoE and Wi-Fi connectivity |
|
|
|
|
|
|
|
|
|
|
|
