| Specification |
|
| Number of Doors Controlled |
1 Door |
| Number of Readers Supported |
2(26-bit wiegand reader) |
| Types of readers supported |
26-bit Wiegand, others upon request |
| Number of Inputs |
2 (Exit Device and Door Status, AUX) |
| Number of Outputs |
2 (1-From C Relay for Lock and 1-Form C Relay for Aux Output) |
| Card holders Capacity |
30,000 |
| Log Events Capacity |
1,00,000 |
| Communication |
TCP/IP, RS-485 and WiFi optional |
| Enclosure |
Powder Coated Aluminium |
| Operating Humidity |
20% to 80% |
| Weight |
7.4lbs (3.35kg) |
| Mounting |
Wall Mount |
| CPU |
32 bit 400MHz CPU |
| RAM |
32M |
| Flash Memory |
128M |
| Recommended Power Supply |
12V DC, 1.5A |
| Operating Temperture |
0 – 45 °C |
| Dimensions (Bundle Only) |
15in.×3.15in.×11in.
380mm(L) X 80mm(W) X 280mm(H) |
| Dimensions ( Board Only) |
6.3in.×4.17in.
(160mm×106mm) |
|
|
Features |
| – |
256 time Zones, 256 access levels |
| – |
Anti-passback function |
| – |
Interlock function , Linkage function |
| – |
Multi-Card Opening function, Remote door opening |
|
and closing |
| – |
Real-Time monitoring Via Web browser |
| – |
1 auxiliary input may be connected to infrared body |
|
detectors,Fire alarms, smoke detectors etc. |
| – |
1 auxiliary output may be connected to alarms, |
|
cameras,door bells etc. |
|
|
|
Software and Database Supported : |
| – |
Access Security System 3.5 ( Desktop |
|
Version) Database Type:- MS Access / MS SQL |
|
